Connectors

These male pins can be crimped on 22-28AWG wires and snapped into our crimp connector housings to create custom cables that are compatible with standard 0.1"-pitch headers and solderless breadboards. Our wires with pre-crimped terminals and premium jumper wires use these same pins. One male crimp pin pack consists of 100 pins.

These female pins can be crimped on 22-28AWG wires and snapped into our crimp connector housings to create custom cables that are compatible with standard 0.1"-pitch headers and solderless breadboards. Our wires with pre-crimped terminals and premium jumper wires use these same pins. One female crimp pin pack consists of 100 pins.

This connector adapts a 5.5 × 2.1 mm DC barrel plug to a pair of screw terminals spaced approximately 5 mm (0.2″) apart. The terminals are labeled positive and negative, with the positive terminal connected to the center contact.

This connector adapts a 5.5 × 2.1 mm DC barrel jack to a pair of screw terminals spaced approximately 5 mm (0.2″) apart. The terminals are labeled positive and negative, with the positive terminal connected to the center pin.

This is a standard PCB-mountable barrel-type jack for DC power adapters with 2.1 mm center holes.

IDC socket 2.54mm 6-pin (with strain relief clip) for use with 2×3-pin shrouded male header.

Blue shorting block (removable jumper) designed for 0.1" (2.54 mm) male header pins.

Yellow shorting block (removable jumper) designed for 0.1" (2.54 mm) male header pins.

Black shorting block (removable jumper) designed for 0.1" (2.54 mm) male header pins.

Red shorting block (removable jumper) designed for 0.1" (2.54 mm) male header pins.

These shrouded, 2-pin JST XH-style male connectors have straight leads and match the female connector on the 2-pin female XH-style cable, and they also work with many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of four units.

These shrouded, 2-pin JST XH-style male connectors have right-angle leads and match the female connector on the 2-pin female XH-style cable, and they also work with many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of four units.

These shrouded, 2-pin JST XH-style male connectors have extended right-angle leads and match the female connector on the 2-pin female XH-style cable, and they also work with many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of four units.

These shrouded, 5-pin JST XH-style male connectors have straight leads. They can be used with female JST XH-style connectors, and they also work with many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of two units.

These shrouded, 5-pin JST XH-style male connectors have right-angle leads. They can be used with female JST XH-style connectors, and they also work with many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of two units.

These shrouded, 5-pin JST XH-style male connectors have extended right-angle leads. They can be used with female JST XH-style connectors, and they also work with many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of two units.

These are generic connectors similar to the popular Deans Ultra Plug connectors. They are sold as matching male-female pairs and have a current rating of 50 A. They are the smallest high-current connectors we know of, and they are great for projects that involve bigger motors and controllers, such as our Simple Motor Controllers and high-power motor drivers.

These high-current (60 A) XT60 connectors are commonly used in the RC hobby industry. They are sold as matching male-female pairs and are great for projects that involve bigger motors and controllers, such as our high-power motor drivers and Simple Motor Controllers.

This style of high-current connector is commonly used with the 7.2V sub-C battery packs that power many RC cars. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. You can use a crimping tool to attach these connectors to your own 14- to 20-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 female connectors.

This style of high-current connector is commonly used with the 7.2V sub-C battery packs that power many RC cars. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. This female Tamiya connector has 10cm 14-AWG leads with stripped and tinned terminations.

This style of high-current connector is commonly used with the 7.2V sub-C battery packs that power many RC cars. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. You can use a crimping tool to attach these connectors to your own 14- to 20-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 male connectors.

This style of high-current connector is commonly used with the 7.2V battery packs that power many RC cars. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. This male Tamiya connector has 10cm 14-AWG leads with stripped and tinned terminations.

This connector, a smaller version of the female Tamiya connector, is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. You can use a crimping tool to attach these connectors to your own 16- to 20-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 female connectors.

This connector, a smaller version of the female Tamiya plug, is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. This female mini Tamiya connector has 10 cm 18-AWG leads with stripped and tinned terminations.

This connector, a smaller version of the male Tamiya connector, is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. You can use a crimping tool to attach these connectors to your own 16- to 20-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 male connectors.

This connector, a smaller version of the male Tamiya plug, is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed, and a latch secures the connection so that it will not become disconnected. This male mini Tamiya connector has 10 cm 18-AWG leads with stripped and tinned terminations.

This JST RCY plug is also referred to as a BEC (battery eliminator circuit) connector and is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed. You can use a crimping tool to attach these connectors to your own 22- to 28-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 female connectors.

This female JST RCY plug, also called a BEC connector, has 10 cm 20-AWG leads with stripped and tinned terminations. The connector is keyed so that power cannot be reversed.

This JST RCY plug is also referred to as a BEC (battery eliminator circuit) connector and is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed. You can use a crimping tool to attach these connectors to your own 22- to 28-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 male connectors.

This male JST RCY plug, also called a BEC connector, has 10 cm 20-AWG leads with stripped and tinned terminations. The connector is keyed so that power cannot be reversed.

This 5.5" (14cm) cable has two 26AWG conductors with a 2mm-pitch 2-pin female JST PH-style connector. The other ends of the wires are unterminated; they can be cut to length to match your application. The red and black wires are twisted together to reduce noise.

This 12-inch (30-cm) cable has 26 AWG wires and a 3-pin female JST PH-style connector that works with Sharp analog distance sensors that have mating PH connectors. The other ends of the wires are unterminated; they can be cut to length to match your application. The wire color scheme matches the Sharp distance sensor pinout: red for power, black for ground, and white for signal.

This 12-inch (30-cm) cable has 28 AWG wires and a 3-pin female JST ZH-style connector that mates with the 3-pin connector on Sharp GP2Y0A51 analog distance sensors. The other ends of the wires are unterminated; they can be cut to length to match your application. The wire color scheme matches the Sharp distance sensor pinout: red for power, black for ground, and white for signal.

This pack contains everything you need to add up to three female JR connectors — the connectors commonly found on generic RC servos — to custom cables. You can use a crimping tool to attach the included pins to your own 22–26 AWG wires. This pack contains enough housings and crimp pins (including 3 spare pins) for 3 female connectors. The crimp pins have gold-flashed female contacts.

This pack contains everything you need to add up to three male JR connectors — the connectors that mate with those commonly found on generic RC servos — to custom cables. You can use a crimping tool to attach the included pins to your own 22–26 AWG wires. This pack contains enough housings and crimp pins (including 3 spare pins) for 3 male connectors. The crimp pins have gold-flashed male contacts.

This pack contains everything you need to add up to three female Futaba J connectors — the connectors found on many Futaba servos — to custom cables. You can use a crimping tool to attach the included pins to your own 22–26 AWG wires. This pack contains enough housings and crimp pins (including 3 spare pins) for 3 female connectors. The crimp pins have gold-flashed female contacts.

This pack contains everything you need to add up to three male Futaba J connectors — the connectors that mate with those found on many Futaba servos — to custom cables. You can use a crimping tool to attach the included pins to your own 22–26 AWG wires. This pack contains enough housings and crimp pins (including 3 spare pins) for 3 male connectors. The crimp pins have gold-flashed male contacts.

These stackable 0.1" (2.54 mm) female headers are just the right height for connecting Arduino shields to Arduinos and other shields. The set includes two 1×6 female headers, two 1×8 female headers, and one 1×10 female header, so it has everything necessary for both old- and new-style shields.
