Lidar/Time-of-Flight Range Finders

This board is a 3-channel time-of-flight proximity and distance sensor module based on the OPT3101 IC from Texas Instruments. It emits infrared light in one of three selectable directions with its six integrated LEDs and measures distance by measuring the time delay of the reflected signal. Distance measurements can be read through a digital I²C interface. The combined field of view of the three sensing zones is almost 180 degrees, and the maximum range is about one meter. This module does not include any headers; we carry an alternate version with headers soldered.

This board is a 3-channel time-of-flight proximity and distance sensor module based on the OPT3101 IC from Texas Instruments. It emits infrared light in one of three selectable directions with its six integrated LEDs and measures distance by measuring the time delay of the reflected signal. Distance measurements can be read through a digital I²C interface. The module is designed to mount to the front of the TI-RSLK MAX robot. The combined field of view of the three sensing zones is almost 180 degrees, and the maximum range is about one meter.
