Terminal Block 2-Pin 5mm Pitch
These are low cost, screw-style terminal blocks with 5.0 mm pitch. Each unit has two terminals; units slide together to make longer strips. 300 VAC/15 A rating.
Note: This product has been replaced by compatible versions from another supplier. The replacements ship in packs of four.
| Description | Specs (5) | Pictures (1) | Resources (0) | FAQs (0) | On the blog (0) |
|---|
Note: This product has been replaced by compatible versions from another supplier. The replacements ship in packs of four. You can find our entire, newly expanded offering of terminal blocks here.
 |
Specifications:
- Voltage rating: 300 VAC
- Current rating: 15 A
- Wire range (AWG): 14-22
- Wire strip length: 6-7 mm
