Tamiya Motors and Gearboxes

Tamiya’s double gearbox packs two independent gear trains into a compact and affordable package that is great for small mobile robots. Each side can be assembled to have one of four gear ratios: 12.7:1, 38:1, 115:1, or 344:1.

Tamiya’s twin-motor gearbox consists of two independent brushed DC motors and gearboxes in one compact housing, making it perfect for small robots. You can assemble the gearboxes to have a 58:1 or a 204:1 gear ratio.

This gearbox features a low-current brushed DC motor, which is great for projects where you want to keep your power consumption to a minimum. Its single gear train can be assembled to have one of three gear ratios: 12.7:1, 38.2:1, or 114.7:1.

Tamiya’s 4-speed low-speed mini motor gearbox features a more compact 030-form-factor brushed DC motor driving a single gear train that can be assembled to have one of four gear ratios: 71.4:1, 149.9:1, 314.9:1, or 661.2:1. The gear train includes a self-locking worm gear.

Tamiya’s 8-speed mini motor gearbox features a more compact 030-form-factor brushed DC motor driving a single gear train that can be assembled to have one of eight gear ratios: 7.5:1, 9.5:1, 15.7:1, 19.9:1, 32.9:1, 41.8:1, 79.1:1, or 87.8:1.

Tamiya’s 12-speed multi-ratio mini motor gearbox features a more compact 030-form-factor brushed DC motor driving a single gear train that can be assembled to have one of twelve gear ratios: 4.6:1, 5.1:1, 9.7:1, 10.8:1, 20.4:1, 22.6:1, 42.8:1, 47.5:1, 89.9:1, 99.8:1, 188.7:1, or 209.7:1.

The single gearbox is perfect if you like the gear ratio options of the 70168 double gearbox but need just one motor or added flexibility in positioning multiple output shafts. Available gear ratios are: 12.7:1, 38:1, 115:1, or 344:1.

Tamiya’s 3-speed crank-axle gearbox looks very much like half of the twin-motor gearbox (with an added gear ratio option). This compact gearbox can be built in one of three gear ratios (17:1, 58:1, and 204:1), and is Tamiya’s cheapest, general-purpose gearbox.

This gearbox has four possible gear ratios, including the highest gear ratio of Tamiya’s gearbox series, 5402:1. The other options are 126:1, 441:1, and 1543:1. This gearbox also features a worm gear, which locks the output shaft when the motor is not turning.

Unlike the other gearboxes in Tamiya’s series, the universal gearbox has a thin metal frame, making it the smallest Tamiya gearbox. The final two gears are metal, making for a tough output. A worm gear allows for the high gear ratio options of 101:1, 269:1, and 719:1.

The first in Tamiya’s “high efficiency” series, the planetary gearbox features two 4:1 and two 5:1 stages that can be combined in any way you like—you can even combine two kits to get really huge gear ratios. The output is always conveniently on the same axis as the motor shaft. Available gear ratios are 4:1, 5:1, 16:1, 20:1, 25:1, 80:1, 100:1, and 400:1.

The high-speed gearbox can be assembled in 11.6:1 and 18:1 gear ratios. This high-efficiency gearbox is therefore suited for very fast vehicles or other fast mechanisms that do not require high torque.

With possible gear ratios of 41.7:1 and 64.8:1, the high-power gearbox is well-suited for most vehicles that require a balance of speed and torque.

The primary feature of this high-efficiency gear box is a worm gear, which locks the output shaft whenever the motor is not turning. The high gear ratios of 216:1 or 336:1 make this gearbox appropriate for small walking robots, lifting mechanisms, and other applications where high torque is desired.

This versatile, high-efficiency gearbox lets you build one of the following gear ratios: 11.6:1, 29.8:1, 76.5:1, 196.7:1, 505.9:1, and 1300.9:1. Whatever your application, chances are that one of the configurations will do the job.

With possible gear ratios of 39.6:1, 47.6:1, 61.7:1, and 74:1, the Tamiya 72007 4-Speed High-Power Gearbox is well-suited for most applications that require a balance of speed and torque.

The primary feature of this gearbox is a worm gear, which locks the output shaft when the motor is not turning. Its high gear ratios of 84:1, 216:1, 555.4:1, and 1428.2:1 make this gearbox appropriate for small walking robots, lifting mechanisms, and other applications where high torque is desired.
